Carlson BRx7 GNSS Receiver

Name: Carlson BRx7 GNSS Receiver
SKU: 896
Availability: InStock

$12,995.00 – $25,250.00

Call Us at 888-299-6996 for Available Discounts.

The BRx7 GNSS receiver with SurvCE/SurvPC delivers a modern and flexible GNSS RTK product for precision surveys, with an intuitive and familiar application software. The lightweight BRx7 receiver may be used as a Rover, or as a Base to send corrections to RTK UAVs or GNSS Rovers.

Options

Clear

SKU: N/A Category: Carlson Field Instruments Tags: GNSS, GPS

The package includes the following components for a single rover kit:

1 Brx7 GNSS Receiver
Hard Case
Measuring Tape (Included only with Base and Rover Package)
1 BRx7 Power Cable to Receiver & DB-9 Serial
1 GPS Tribrach w/ Optical Plummet (Included only with Base and Rover Package)
1 1 X S Series Dual Battery Charger
2 1 X S Series BP-5S Battery
1 1 X S Series Battery Charger Adapter
1 5-pin Serial Cable
1 Quick Release Adaptors
1 Carlson Brx6 Power Cable w/ Clips
1 Tribrach Adapter/Carrier (Included only with Base and Rover Package)
1 BRx7 GPRS Antenna (SMA)
1 BRx7 UHF Antenna
1 1.405 inch/35.7mm Height Adapter

Carlson BRx7 Brochure

Description

Product Description:

The BRx7 is Carlson’s all-new multi-GNSS, multifrequency smart antenna. The BRx7 provides robust performance and high precision in a compact, rugged package with tilt compensation ability. With multiple wireless communication ports and an open GNSS interface, the BRx7 can be used in a variety of operating modes.
Use the BRx7 as a precise network rover to work with your GNSS VRS network, or set up your BRx7 as an easy-to-use base-rover package with industry-leading performance via the internal long range and spread-spectrum radio or cellular communication via Carlson’s Listen-Listen, a unique cloud-based low latency service that eliminates baseline length restrictions of UHF radios. With only an Internet connection, you can enjoy a simple, easy-to-use base-rover solution that can also support a single base with multiple simultaneous rover connections.
The BRx7 provides state-of-the-art RTK performance when receiving corrections from a static base station or network RTK correction system. With multiple connectivity options, the BRx7 allows for RTK corrections to be received over radio, cell modem, Wi-Fi, Bluetooth, or serial connection. The BRx7 delivers centimeter-level accuracy with virtually instantaneous initialization times and cutting edge robustness in challenging environments.
The BRx7 also features proprietary SureFix® technology to provide high fidelity information about the quality of the RTK solution, allowing enhanced and improved RTK accuracy, availability, and precision.
The built-in web user interface (WebUI) can be used to monitor and control the receiver status and operation, as well as to upgrade the BRx7 with new firmware and activations. The BRx7 is immune from magnetic interference, and is both Athena™ -enabled and Atlas® -capable (subscription required).

KEY FEATURES

• Multi-frequency GPS, GLONASS, BeiDou, Galileo, QZSS, IRNSS, and Atlas L-band
• Long-range RTK baselines up to 50 km with fast acquisition times with the use of Listen-Listen***
• UHF (400 MHz & 900 MHz), cellular, Bluetooth, and Wi-Fi wireless communication
• The BRx7 Athena GNSS engine providing best-in-class RTK performance
• Internal tilt sensor corrects collected point coordinates to within 2 cm
